HYP2 250KN 300KN 25T 30T Plane Hydraulic Cutting Machine

Short Description:

Product Detail

Product Tags

Uses and features

The machine is mainly suitable for cutting nonmetal materials such as leather, plastic, rubber, canvas, nylon, cardboard and various synthetic materials.
1. The principal axis is adopted automatic lubricating system which supplies oil to prolong the service life of the machine.
2. Operate by both hands, which is safe and reliable.
3. The area of cutting pressure board is large to cut large-sized materials.
4. The depth of cutting power is set to be simple and accurate.
5. The height of return stroke of the platen can be set arbitrarily to reduce idle stroke.

How a Beam Press Works?

A beam press is one of machine press which have mechanical beam press and hydraulic beam press.
Mechanical beam presses are forging machines driven by crank linkage or elbow rod mechanism, cam mechanism, screw mechanism, and are used for pressure processing of materials.In the other words,The crank-slider mechanism converts the rotational motion of the motor into a linear reciprocating motion of the slider, thus creating pressure on the material and achieving the desired working result.
The hydraulic beam press is consists of basic components used in a hydraulic system that includes the cylinder, pistons, the hydraulic pipes.The oil pump delivers the hydraulic oil to the integrated cartridge valve block, which distributes the hydraulic oil to the upper or lower chamber of the cylinder through each check valve and relief valve, and makes the cylinder move under the action of high pressure oil.Hydraulic Beam presses follow the Pascal’s law: increase the pressure on a closed liquid, which can be constant, that is, the liquid is equally transmitted to each point.

What are The Types of Beam Presses?

If you want to buy beam presses for your production . There have many types of beam presses for your choice.
The below types of beam presses that is important you consider all the available types of beam presses.

TECHNICAL SPECIFICATION

Model	HYP2-250/300
Maximum Cutting Force	250KN/300KN
Cutting area（mm）	1600*500
Adjustment Stroke（mm）	50-150
Power	2.2
Machine’s dimensions（mm）	18306501430
G.W	1400
