HYA2-120/160/200 12T 16T 20T Swing Arm Hydraulic Cutting Press Machine

Short Description:

Product Detail

Product Tags

Uses and features

The machine is used to cut vamps, soles, leather, rubber, chemical fibre, hard paper and cotton fabrics.
1. Adopt automatic lubricating system which supplies oil to reduce abrasion and prolong the service life of the machine.
2. Time-lapse electronic circuit controls the bottom position of stroke, which makes precision high and raises quality of shoes. Adjust the height of swing arm apart from working table to make operation simply, reliable and convenient.

Hydraulic swing arm cutting machine/clicker press/die cutting machine

Our machine's die cutting range is huge of uses and applications across manufacturing industry, known as clicking press or clicker press.
These machines are safe and easy to operate with the operator having only to place the material on the working table of the press, position the cutting tool on the material and press the button on the handle. The beam descends under hydraulic power to cut the required cut shape from single or multiple layers of material.
To assure maximum access and visibility, the swing arm can be easily moved to one side by the operator in order to gather cut pieces and re-position the tool for the next cut.

Did you know?

The machines are often known as ‘clicker press’ due to the historic way of cutting patterns in the shoe industry?
Originally, leather cutting operators used to produce cut parts by using a hand held knife which they would run around a pattern or template. These patterns had a brass edging to protect the template and as the blade ran round the brass edging it produced a clicking sound. Hence the operators became known as ‘clickers’. With the development of swing arm presses to do this job, the machines became known as clicker press or clicking press. The term remains in use to today.

Features

* Cut materials that are soft or semi-rigid
* Cut materials in single or multiple layers
* Fast, quiet, easy to operate
* Swing beam (arm) allows full access and visibility
* Use all standard tool types – strip steel, wood form, forged steel
* Low friction swing beam (arm) Varying tool heights can be used without adjustment
* Double acting hydraulic cylinder
* Simple daylight adjustment
* Quiet, vibration free operation
* Safe, twin button operation
* Complete with high grade polypropylene cutting board, hydraulic oil and operating manual

TECHNICAL SPECIFICATION

Series	Max cutting pressure	Engine power	Size of the working table	Stroke	N.W
HYA2-120	120KN	0.75KW	900*400mm	5-75mm	900KG
HYA2-200	200KN	1.5KW	1000*500mm	5-75mm	1100KG
